SS 410 SOFF Backing Flanges Manufacturer in India

ASME B16.5 / ANSI B16.47 150# & 300#

Stainless Steel 410 Backing Ring Flange
Stainless Steel 410 Backup Flange Manufacturer

Stainless Steel 410 Backing Ring Flange Manufacturer

Stainless Steel 410 Backup Flange, SS 410 Backing Ring Flange Supplier, ASME B16.5 Grade 410 Backing Flange Exporter, ASTM A182 SS410 Loose Backing Flange, ANSI B16.47 SS 410 Split Backup Flange, BS4504 PN10/16 Backing Ring Manufacturer in India.

Taurus Piping Solutions (TPS) is one of the best Stainless Steel 410 Backing Ring Flange Manufacturers, Suppliers and Exporters of India. We have a big clientele base, whom we have served with all our heart and dedication over the past years. Our focus is to become a globally acclaimed brand with primary focus on high-end quality products and effective after sales services. Apart from being top-notch in quality, our products are available at affordable market prices. The Stainless Steel 410 Backing Ring Flanges are austenitic stainless steel made out of raw materials. They have an added tinge of molybdenum, which makes it better resistant to corrosion.

SS 410 Backing Ring Flanges is a circular metal ring, with holes around the perimeter, used in pairs to bolt two HDPE pipes together, or used when installing flanged components, e.g. water meters, wafer valves, check valves. This allow length of PE pipe to be disconnected and re connected, for inspections, replacement, or relocation.

SS 410 Backup Flange Specification

  • Standard : AS 2129 Table D, E, F, H, J,K, R, S & T, ANSI, ASME, EN1092, JIS, SABS1123, GOST-12820, AS/NZS 4087
  • Dimensions : ANSI B16.5, ANSI B16.47, Series A & B
  • BS : BS4504, BS10
  • Class : 150 LBS, 300 LBS
  • Pressure : PN6, PN10, PN16, PN25, PN40, PN64, PN100, PN160
  • Size : ½” (15 NB) to 48″ (1200NB)
  • Type : Backing Ring Flange / Backup Flange

Stainless Steel UNS S41000 Backing Ring Flange, DIN 1.4006 Backup Flange Manufacturer, Stainless Steel JIS SUS 410 BRF, BS 410S21 Backup Ring, EN X12Cr13 Backing Flange Exporter in India, Grade 410 Stub Flange and Backing Ring, SS 410 Back Up Flanges Exporter in Australia.

Stainless Steel 410 Backing Rings Flanges are used in PE100 PE pipelines to connect flanged valves, flange adaptors and other flanged made of DI or Stainless Steel. The 410 Backing Ring Flanges is matched to the steel or DI pipe flange specification and is placed behind the PE100 PE stub flange which is butt welded to the PE100 PE pipe. SS 410 Backing rings to comply with AS/NZS 4087 Figure B7 and MRWA-W-306B. Material of make Stainless Steel 410 to ASTM A182.

Stainless Steel 410 backing ring flange for water supply and sewerage. We have become a renowned brand in many countries across the globe like Italy, Finland, Spain, Portugal, Belgium, UK, France, Philippines, Ghana, South Africa, Kenya, Mozambique, Rwanda, Zimbabwe.

SS 410 Backing Ring Flange Equivalent Grades

Standard W.N. UNS JIS BS GOST AFNOR EN
SS 410 1.4006 S41000 SUS 410 410S21 - - X12Cr13

Stainless Steel 410 Backup Flange Chemical Composition

Grade C Mn Si P S Cr Mo Ni N
SS 410 0.15 max 1.0 max 1.0 max 0.040 max 0.030 max 11.5 – 13.5 0.50 max

SS 410 Backing Ring Flange Mechanical Properties

Tensile Strength ksi (MPa) min Yield Strength 0.2% offset ksi (MPa) min Elongation (% in 50mm) min Hardness (Brinell) MAX Hardness (Rockwell B) MAX
65 (450) 30 (205) 20 217 96

410 Stainless Steel Backup Flanges Applications and Uses

Our Stainless Steel 410 Backup Flanges are used in a wide range of applications and various industries. Below are a few of them:

Refineries
Power Generation
Mining Industry
Engineering & General Piping
Offshore Oil Drilling Companies
Pharmaceuticals
Construction & Water Pipeline
Petrochemicals & Nuclear

Other Types Of SS 410 Soff Backing Ring Flanges

SS 410 Soff Backing Ring Flange

SS 410 Backing Ring FlangeASTM A182 SS 410 Backing Ring FlangesASME B16.47 Grade 410 Backup FlangeBS 410S21 Backing Ring FlangesEN X12Cr13 Backup RingASME SA182 SS 410 Back Up Flanges

Stainless Steel 410 Backup Flanges

SS 410 B16.5 Sorf Ring FlangeDIN 1.4006 Backup Ring FlangeUNS S41000 Backing Ring Flanges410 Stub Flange and Backing RingStainless Steel 410 BRFJIS SUS 410 PN16 Backup Flanges

Documentation & Packaging

Commercial Invoice including HS Code

Packing List including Complete Details

Certificate of Origin legalized

Material Traceability Records

Quality Assurance Plan (QAP)

Heat Treatment Charts

Material Test Certificates (MTC)

NABL approved Laboratory Test Reports

Material Testing

Mechanical Testing Such as Tensile of Area

Hardness Test

Chemical Analysis – Spectro Analysis

Positive Material Identification – PMI Testing

Flattening Test

Taurus Piping Solutions is ISO Certified Manufacturers and Suppliers of Stainless Steel 410 Backing Ring Flange: Weld Neck Backing Flange, BS4504 PN10/PN16 Backup Ring, BS10 Table D & Table E Backup Flange, ASA 150 Back Up Flanges, SS 1.4006 Stub Flange and Backing Ring, Loose Backing Flange, Backing Ring For PVC Flange, Backing Flange PP-Steel, Backup Flange Dimensions, Split Backup Flange, Convoluted Flange/ Backup Ring, Backing Flange and Stub End, Backing Flange and Collar, ANSI Backing Flange, UNS S41000 Backing Flange Size Chart, PN16 Backing Flange Dimensions, Backing Ring For Stub Flange, IPS Backing Flange, Flange Backing Plate, Backing Flange Standard, 2 Piece Backing Flange, 4 Inch Backing Flange, Flange Adapter With Backing Ring in Australia, New Zealand, Middle East, USA, South Africa, UK.
