SS 347H SOFF Backing Ring Flanges Manufacturer in India

ASME B16.5 / ANSI B16.47 150# & 300#

Stainless Steel 347H Backup Flange
Stainless Steel 347H Backing Ring Flange Manufacturer

Stainless Steel 347H Backing Ring Flange Manufacturer

Stainless Steel 347H Backing Ring Flange, SS 347H Backup Flange Supplier, ASME B16.5 Grade 347H Backing Flange Exporter, ASTM A182 SS347H Loose Backing Flange, ANSI B16.47 SS 347H Split Backup Flange, BS4504 PN10/16 Backing Ring Manufacturer in India.

Taurus Piping Solutions (TPS) is India's most renowned Stainless Steel 347h Backing Ring Flange Supplier, Manufacturer, and Exporter, having a huge number of satisfied customer base, formed over decades of dedicated service. Our brand is a globally focused venture which primarily focuses on providing high quality and durable SS 347h at an affordable range of pricing. We regard our consumers as the ultimate decision makers and hence value their requirements with utmost importance and commitment.

SS 347h Backing Ring Flanges are used for improving installation time to compensate for poor alignment of valves – especially when retrofitting into metallic pipelines. A quality 347h SS Backing Ring Flange will negate bending effects, especially when connecting to raised face flanges. We stock a large range of quality Backing Rings flange in Stainless Steel, ready for your next project. Available to suit wide range of pipe diameters from OD 20 mm to 1000 mm.

SS 347H Backing Ring Flange Specification

  • Standard : AS 2129 Table D, E, F, H, J,K, R, S & T, ANSI, ASME, EN1092, JIS, SABS1123, GOST-12820, AS/NZS 4087
  • Dimensions : ANSI B16.5, ANSI B16.47, Series A & B
  • BS : BS4504, BS10
  • Class : 150 LBS, 300 LBS
  • Pressure : PN6, PN10, PN16, PN25, PN40, PN64, PN100, PN160
  • Size : ½” (15 NB) to 48″ (1200NB)
  • Type : Backing Ring Flange / Backup Flange

Stainless Steel UNS S34709 Backing Ring Flange, DIN 1.4961 Backup Flange Manufacturer, Stainless Steel JIS SUS 347H BRF, SS 347H Backup Ring, EN X6CrNiNb18-12 Backing Flange Exporter in India, Grade 347H Stub Flange and Backing Ring, SS 347H Back Up Flanges Exporter in Australia.

Stainless Steel 347h Backing rings Flange for use with PE flanges have traditionally been manufactured from Stainless Steel. Ductile iron backing rings offer a technically equivalent and competitive alternative. The PN16 backing rings flanges conform to dimensional, and mating dimension of AS / NZS 4087:2011 Flanges for water supply application with internal diameter conforming to ISO 9624:2019 Thermoplastics piping system for fluid under pressure Flange adapters and, loose backing flanges Mating dimensions.

We carry an extensive range of quality certified SS 347h Backing rings flanges, to suit all applications. Due to high value services, we have become a renowned brand in many countries across the globe like Italy, Finland, Spain, Portugal, Belgium, UK, France, Philippines, Ghana, South Africa, Kenya, Mozambique, Rwanda, Zimbabwe Ethiopia, Mauritius, Turkey, among others.

SS 347H Backing Ring Flange Equivalent Grades

SS 347H 1.4961 S34709 SUS 347H - - - X6CrNiNb18-12

Stainless Steel 347H Backup Flange Chemical Composition

Grade C Mn Si P S Cr Cb Ni Fe
SS 347H 0.04 – 0.10 2.0 max 1.0 max 0.045 max 0.030 max 17.00 - 19.00 8xC – 1.10 9.0 -13.0 63.72 min

SS 347H Backing Ring Flange Mechanical Properties

Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
8.0 g/cm3 1454 °C (2650 °F) Psi – 75000 , MPa – 515 Psi – 30000 , MPa – 205 35 %

347H Stainless Steel Backing Ring Flanges Applications and Uses

Our Stainless Steel 347H Backing Flanges are used in a wide range of applications and various industries. Below are a few of them:

Power Generation
Mining Industry
Engineering & General Piping
Offshore Oil Drilling Companies
Construction & Water Pipeline
Petrochemicals & Nuclear

Other Types Of SS 347H Soff Backing Ring Flanges

SS 347H Soff Backing Ring Flange

SS 347H Backing Ring FlangeASTM A182 SS 347H Backing Ring FlangesASME B16.47 Grade 347H Backup FlangeStainless Steel BS 4504 Backing Ring FlangesSS347H EN X6CrNiNb18-12 Backup RingASME SA182 SS 347H Back Up Flanges

Stainless Steel 347H Backup Flanges

SS 347H B16.5 Sorf Ring FlangeDIN 1.4961 Backup Ring FlangeUNS S34709 Backing Ring Flanges347H Stub Flange and Backing RingStainless Steel 347H BRFAS/NZS 4087 PN16 Backing Ring Flanges

Documentation & Packaging

Commercial Invoice including HS Code

Packing List including Complete Details

Certificate of Origin legalized

Material Traceability Records

Quality Assurance Plan (QAP)

Heat Treatment Charts

Material Test Certificates (MTC)

NABL approved Laboratory Test Reports

Material Testing

Mechanical Testing Such as Tensile of Area

Hardness Test

Chemical Analysis – Spectro Analysis

Positive Material Identification – PMI Testing

Flattening Test

Taurus Piping Solutions is ISO Certified Manufacturers and Suppliers of Stainless Steel 347H Backing Ring Flange: Weld Neck Backing Flange, BS4504 PN10/PN16 Backup Ring, BS10 Table D & Table E Backup Flange, ASA 150 Back Up Flanges, SS 1.4961 Stub Flange and Backing Ring, Loose Backing Flange, Backing Ring For PVC Flange, Backing Flange PP-Steel, Backup Flange Dimensions, Split Backup Flange, Convoluted Flange/ Backup Ring, Backing Flange and Stub End, Backing Flange and Collar, ANSI Backing Flange, UNS S34709 Backing Flange Size Chart, PN16 Backing Flange Dimensions, Backing Ring For Stub Flange, IPS Backing Flange, Flange Backing Plate, Backing Flange Standard, 2 Piece Backing Flange, 4 Inch Backing Flange, Flange Adapter With Backing Ring in Australia, New Zealand, Middle East, USA, South Africa, UK.
