ASME B16.5 / ANSI B16.47 150# & 300#
Table of Content:
Taurus Piping Solutions is noteworthy manufacturer, and exporter of Incoloy 925 Backing Ring Flanges we manufacture these Flanges using superior quality raw materials procured from certified companies and advanced technology equipment. We manufacture these Incoloy 925 Backing Ring Flanges in accordance with globally approved quality standards such as ASTM, ASME, JIS, DIN, and EN standards, in various specifications, sizes, dimensions, pressure classes and also in customized configuration as per the requirements of our client's at reasonable prices.
Incoloy Alloy 925 Flange Backing Ring combines the superior strength of a precipitation-hardenableincoloy alloy825 with the outstanding corrosion resistance. Incoloy 925 Backing Ring Flange is particularly ideal to the sour environments of down-hole crude oil and natural gas well.Incoloy 925 SOFF Backing Ring Flanges exhibit superior strength,excellent resistance to stress corrosion cracking, resist reducing environments, resists general, pitting, crevice and stress corrosion cracking in most aqueous environments where chloride or sulphide ions may be present. Incoloy UNS N08925 Backing Ring Flanges are applicable to tooling applications and reducing suspended load of critical components.
Incoloy 925 Slip on Flat Face Backing Ring Flanges are used in various application areas such as Downhole equipment for corrosive/sour service such as valves, hangers, tool joints and packers, Marine and pump shafts, High strength components, Chemical process industry components, Food processing equipment, Petrochemical Industry, Oil and gas processing, etc.
Our Incoloy 925 Backing Ring Flanges undergo various tests to make sure they are suitable for use in various applications right from procurement of raw materials to the final delivery of flanges. We are the leading Incoloy925 Backing Ring Flanges Exporter in various regions like Australia, New Zealand, Dubai, Abu Dhabi, Oman, Saudi Arabia, South Africa, Canada, Qatar, Bahrain, USA, etc.
| Standard | W.N. | UNS | JIS | BS | GOST | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| Incoloy 925 | - | N09925 | NCF 925 | - | - | - | - |
| Grade | C | Mn | Fe | S | Si | Cr | Ni |
|---|---|---|---|---|---|---|---|
| Incoloy 925 | 0.05 max | 1.00 max | 22.0 min | 0.03 max | 0.05 max | 19.0-23.0 | 38.0-46.0 |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|---|
| Incoloy 925 | 8.14 g/cm3 | 1400 °C (2550 °F) | Psi – 80,000 , MPa – 550 | Psi – 32,000 , MPa – 220 | 30% |
Commercial Invoice including HS Code
Packing List including Complete Details
Certificate of Origin legalized
Material Traceability Records
Quality Assurance Plan (QAP)
Heat Treatment Charts
Material Test Certificates (MTC)
NABL approved Laboratory Test Reports
Other Types Of Incoloy Alloy 925 Soff Backing Ring Flanges
ASME B16.47 Alloy 925 Backing Ring FlangeIncoloy 925 Backing Ring FlangesASME B16.47 Incoloy Alloy 925 Backup FlangeJIS NCF 925 Backing Ring FlangesAS/NZS 4087 Backup RingAS 2129 Table D, E, F, H Grade 925 Back Up Flanges
Alloy 925 Sorf Ring FlangeUNS N09925 Backup Ring FlangeAlloy 925 Backing Ring FlangesAS 2129 Table J, K, R, S, & T Stub Flange and Backing RingIncoloy 925 BRFAS/NZS 4087 PN16 Backing Ring Flanges
