Ductile Iron Backup Flange Dimensions

EN1092, AS2129, AS4087, ASME B16.5, JIS B2220

Nylon Coated Backing Ring Flange Exporters in Bahrain

Split Ring Backing Flanges Specification - Bahrain

  • Standard : AS 2129 Table D, E, F, H, J, K, R, S, and T, ANSI, ASME, SABS1123, JIS, GOST-12820, EN1092, AS/NZS 4087
  • Dimensions : ANSI B16.47, ANSI B16.5, Series A and B
  • BS : BS10, BS4504
  • Class : 150 LBS, 300 LBS
  • Pressure : PN160, PN100, PN64, PN40, PN25, PN16, PN10, PN6
  • Size : ½”(15 NB) to 48″(1200NB)
  • Material : Mild Steel Galvanised, Ductile Iron, Stainless Steel, Duplex & Super Duplex, Carbon Steel, Alloy Steel, High Nickel Alloys
  • Quality : Manufactured ISO 9001, Material Certificates Supplied
Split Flange Backing Ring Suppliers in Bahrain

SS 304 / 304L Backing Ring Flange in Bahrain

Split Ring Backing Flanges, Stub Flange with Backing Ring, Backing Flanges, Ductile Iron Backup Flange, Backing Ring Dimensions, Galvanized Backing Flange, Lap Joint Flange Backing Ring, Split Flange Backing Ring, Backing Ring Flange, Ring Flange, Backing Flange Dimensions, Ductile Iron Backup Flange Dimensions, Stainless Steel Backing Ring Flange, Hot Dip Galvanized Backing Ring Flange, Nylon Coated Backing Ring Flange, DI Backup Flange in Bahrain.

Taurus Piping Solutions (TPS) is an Indian origin manufacturers of Backing Ring Flanges. We are largely exporting our Split Flange Backing Ring in Bahrain by covering different cities like Manama, Al Muharraq, Ar Rifā‘, Dār Kulayb, Madīnat Ḩamad, Madīnat ‘Īsá, Sitrah, Jidd Ḩafş, Al Ḩadd, Etc.

Difference in choice between using a full face flange or stub and backing ring. Now, a stub and backing ring has a ring that comes off and spins freely around it, and the seal is on the stub section here. whereas, on a full face flange the, in effect, stub and backing ring are all one part. so its all one part together, all fused together. so, why would you choose one over the other? well, full face flanges are cheaper than stubs and backing rings, that's one reason some people sometimes prefer to use full face flanges; but, the real reason is in the intallation. If you imagine we're installing a pipline and our pipeline is being flanged together, so there's flanges on the end of each pipeline, if we have a fixed flange - like this full face flange - one the end of each pipeline, when we try and marry the next one up to it, the holes have to marry up perfectly with this, because we haven't got any give at all in where the holes are on the flange on this side. that actually makes it quite difficult when you're assembling lengths of pipe which have already been flanged, because the flanges have to match up perfectly with the flange next to it.

If, however, you had a fixed flange on one end and then a flange like this with a spinning backing ring on the other, it doesn't matter where this flange is glued (fixed) on, because when this one marries up to it, we can always spin it and you can always match the holes up. So, a flange and backing ring make it much easier for installing a system.

If you imagine if you've got a pump or a gib valve or a big filter, which you're wanting to bolt a flange to, again, you can take your pipe work to it, you can connect your stub on, making sure your backing ring's already on the pipe before you glue (fixed) the stub on - otherwise, if you haven't, then you're never going to get the backing ring on that; that's a mistake people sometimes make.

So, if you glue (fixed) this on, you can then, at your leisure, marry it up to the pump, or marry it up to the flange, turn the ring to line up, and you can get it lining up perfectly. If you've got a full faced flange which you've already got glued (fixed) onto your pipe, and there's an elbow coming after it, its very difficult to get that match up perfectly onto the flange on the pump or on a valve, which might be fixed in place already. So, I tend to favour, wherever possible, use a flange and backing ring because its a much more flexible, much more easy to install part than the full face flanges.

  • Constructed with a high strength steel core and polypropylene corrosion-resistant over-mold
  • Light-weight backing flange for use with face rings and buttweld stub ends.
  • Backing rings provide a complete solution for superior protection against highly corrosive applications.
  • Corrosion-resistant alternative to coated flange backing rings, Low-cost
  • Standard 150lb ANSI bolt pattern
  • Backing flanges suitable for the use with PE flange adaptors in the sizes DN20 through to DN1000 and flanges in accordance with ANSI/ASTM B16.5, AS 2129, AS/NZS 4331.1 (ISO 7005-1) and AS 4087.
